SymCom 350-600-2 Three-Phase Voltage Monitor

SymCom 350-600-2 Three-Phase Voltage Monitor

Usually ships within 1 week

SKU : MSR350-600-2

In Stock Quantity:0

:
Brand : Littelfuse/Symcom
$301.22 USD
Shipping calculated at checkout.

Description

Littelfuse 350-600-2 Voltage Monitor Product Description

The 350 is a heavy-duty voltage monitor. This product should be used when high current relays or dual contacts are required, or 480V controls are used. Since the 350 uses heavy-duty relays, it comes in fixed voltage range models rather than a dual autoranging version like the Model 250.

The 350-200 has a 15A general purpose contact. The 350-400 provides a SPDT (Form C) relay rated to switch up to 600V, allowing the use of 480V controls, eliminating the need for a control power transformer to step the voltage down to 120-240V. Several DPDT (two Form C contacts) relay models are also available.

The 350 microcontroller-based family of products are low cost yet highly advanced solutions to heavy-duty problems. The 350 includes advanced single LED diagnostics. Five different light patterns distinguish faults and normal operating conditions. Other options such as high voltage trip and adjustable restart delay are available.

Littelfuse 350-600-2 Voltage Monitor Typical Applications

  • Fans
  • Compressors
  • HVAC
  • Heat Pumps
  • Well Pumps
  • Sump Pumps
  • Small Conveyor Motors
  • Oil Rigs

Littelfuse 350-600-2 Voltage Monitor Features

  • Protects Motor From:
    • Phase Loss (single phasing)
    • Phase Reversal
    • Low Voltage
    • Optional High Voltage
    • Voltage Unbalance
    • Phase Reversal
  • Optional 15A @ 240VAC High Current Relay can Switch Heavier Current Loads.
  • Universal Range from 475-600 VAC 50/60 Hz Provides the Versatility needed to Handle Global Applications.
  • Bicolor LED Indicator Light is Green in Normal Conditions and Red During Trip Conditions.
  • Microcontroller Based Provides Better Accuracy and Higher Reliability than Analog Designs.
  • Transient Protected to Meet IEC 1000-4-5:1995 Standards and Stand up Under Tougher Conditions.
  • DPDT Relay Provides Two 10A @ 240 VAC General Purpose Relays to Switch Heavier Loads.
  • Will Detect Single Phase Condition Regardless of Regenerated Voltages.
  • DPDT Contacts
  • Adjustable Restart Delay
  • Diagnostic LED
  • UL Listed
  • CSA Approved
  • 5-Year Warranty
  • Made in USA

Specifications

Littelfuse 350-600-2 Voltage Monitor Specifications

3-Phase Line Voltage . . . . . . . . . . . . 475 to 600 VAC

Frequency . . . . . . . . . . . . . . . . . . . . . 50*/60Hz

Low Voltage (% of setpoint)

  • Trip . . . . . . . . . . . . . . . . . . . . . . . . . . 90%
  • Reset . . . . . . . . . . . . . . . . . . . . . . . . . 93%

Voltage Unbalance (NEMA)

  • Trip . . . . . . . . . . . . . . . . . . . . . . . . . . 6%
  • Reset . . . . . . . . . . . . . . . . . . . . . . . . . 4.5%

Trip Delay Time

  • Low Voltage . . . . . . . . . . . . . . . . 4 seconds
  • Unbalance & Phasing Faults . . . . . . . 2 seconds

Restart Delay Time

  • After a Fault . . . . . . . . . . . . . . . . . 2 seconds
  • After a Complete Power Loss. . . . . . . 2 seconds

Output Contact Rating

  • SPDT (350200) . . . . . . . . . . . . . . . . . . . . . . . . 480VA @ 240VAC Pilot Duty
  • . . . . . . . . . . . . . . . . . . . . . . . . . . . . or 15A General Purpose
  • SPDT (350-400,350-600) . . . . . . . . . . . . . . . . . 470VA @ 600VAC
  • DPDT(-6 Option) . . . . . . . . . . . . . . . . . 1-10A General Purpose
  • . . . . . . . . . . . . . . . . . . . . . . . . . . . . or 480VA @ 240VAC Pilot Duty
  • . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-15A General Purpose
  • . . . . . . . . . . . . . . . . . . . . . . . . . . . . or 480VA @ 240VAC Pilot Duty
  • . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1hp @ 240VAC
  • DPDT (-8 Option) . . . . . . . . . . . . . . . . . 2-15A General Purpose
  • . . . . . . . . . . . . . . . . . . . . . . . . . . . . 480VA @ 240VAC Pilot Duty
  • . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1hp @ 240VAC

Temperature Range

  • Operating . . . . . . . . . . . . . . . . . -40° to 70°C (-40° to 158°F)
  • Storage . . . . . . . -40° to 80°C (-40° to 176°F)

Trip & Reset Accuracy . . . . . ±1%

Power Consumption . . . . . . . . . . . . . 5 Watts (Max.)

Terminal Torque. . . . . . 7 in.-lbs.

Wire Size. . . . . . 12-18AWG

Transient Protection (Internal). . . . . . IEC 61000-4-5;1995 ±6kV

Safety Marks

  • UL . . . . . . . . . . . . . . . . . UL508 (File #E68520)
  • CSA . . . . . . . 22.2 No. 14 (File #46510)
  • CE . . . . . . . . . . . . . . . . IEC 60947-6-2

Weight . . . . . . . . . . . . . . . . . . . . . . . . 16.8 oz.(1.08lbs)

Mounting Method . . . . . . . . . . . #8 screws

Special Options

  • Option 2: Variable Restart Delay . . . . . . . . . . . Manual, 2-300 seconds adj.
  • Option 5: DPDT Relay
  • Option 6: 2 Relays (1) 10A, (1) 15A
  • Option 8: 2 Relays (2) 15A
  • Option 9: High Voltage (% of setpoint)
    • Trip . . . . . . . . . . . . . . . . . . . . . . . . 110%
    • Reset. . . . . . . . . . . . . . . . . . . . . . . 107%

*Note: 50Hz will increase all delay timers by 20%.
